Our Glass Flake can be applied in anti-corrosive coatings, paints, and pigments to prevent corrosion, and used as a reinforcement material to manufacture composite materials. Its particles form dense, inert barriers within the paint film. Overlapping layers of glass resist water and chemicals permeating the paint film. The addition of glass also increases the flexibility, hardness, and abrasion resistance of coatings.
Chemical Name :
Marine Protection Coating used Glass FlakeApplication :
Suitable for electronic materials, construction industry, aerospace field, anti corrosive coatings, marine protecting.Product model :
KCF-2260Appearance :
Whitebrand :
KmerisSpecification:
Kmeris is a leading manufacture of glass flake, also it is an engineered, performance enhancing mineral products developer. Following an initial research project in the early 1999s to manufacture glass flake for anti-corrosive coatings, the development of the ‘spun method’ of production has enabled the material to expand into a broad range of applications, such as marine protecting coating, industrial anti-corrosive heavy-duty coating, glass flake reinforced epoxy coating, plastic, rubber, pigment and so on!
Project & Standard |
Glass Flake |
|
Product Code |
KCF-2260 |
|
Chemical Analysis |
SiO2 |
64-70% |
K2O |
0-3% |
|
B2O3 |
3-8% |
|
ZnO |
0-5% |
|
Na2O |
10-15% |
|
MgO |
3-8% |
|
CaO |
5-7% |
|
Al2O3 |
3-10% |
|
TiO2 |
0-3% |
|
Physical Properties |
Apparent Density |
1.35 |
(H2O=1) |
|
|
Real Density |
2.60 |
|
(H2O=1) |
|
|
Softening Temperature |
680℃ |
|
DIM 52324 |
|
|
Melt Temperature |
930-1020℃ |
|
(molten - flow) |
|
|
Refractive Index |
1.52 |
|
Particle Size Distribution |
710μm |
0% |
710 μm-150µm |
10% -75% |
|
<150µm |
25% -90% |
|
Thickness |
The nominal thickness of the glass is Av.1±3 microns, can be customized. |
|
Surface coatings |
Glass flake materials are offered with the option of surface pre-treatment with a range of silane coupling agents, listed below (typically 0.8-1.2%wt) : |
|
3-Aminopropyltriethoxy Silane Vinyl trimethoxy Silane γ-Glycidoxypropyltrimethoxy Silane Methacryloxypropyltrimethoxy Silane |
