Our Glass Flake KCF-140 can be applied in anti-corrosive coatings, paints, and pigments to prevent corrosion, and used as a reinforcement material to manufacture composite materials. Its particles form dense, inert barriers within the paint film. Overlapping layers of glass resist water and chemicals permeating the paint film. The addition of glass flake also increases the flexibility, hardness, and abrasion resistance of coatings.
Chemical Name :
Extra corrosion resistant coatings Glass FlakeApplication :
Suitable for electronic materials, construction industry, aerospace field, anti corrosive coatings, marine protecting.Product model :
KCF-140brand :
KmerisSpecification:
Our Glass Flake can be applied in anti-corrosive coatings, paints, and pigments to prevent corrosion, and used as a reinforcement material to manufacture composite materials. Its particles form dense, inert barriers within the paint film. Overlapping layers of glass resist water and chemicals permeating the paint film. The addition of glass flake also increases the flexibility, hardness, and abrasion resistance of coatings.
Extra corrosion resistant Glass Flake manufactured from modified C glass. Available with surface treatments including Vinyl silane, Acrylic silane and etc.
Project & Standard |
Glass Flake |
|
Product Code |
KCF-140 |
|
Chemical Analysis |
SiO2 |
64-70% |
K2O |
0-3% |
|
B2O3 |
2-7% |
|
ZnO |
0-5% |
|
Na2O |
10-15% |
|
MgO |
3-8% |
|
CaO |
5-7% |
|
Al2O3 |
3-10% |
|
TiO2 |
0-3% |
|
Physical Properties |
Apparent Density |
0.75 |
(H2O=1) |
|
|
Real Density |
2.60 |
|
(H2O=1) |
|
|
Softening Temperature |
680℃ |
|
DIM 52324 |
|
|
Melt Temperature |
930-1020℃ |
|
(molten - flow) |
|
|
Refractive Index |
1.52 |
|
Particle Size Distribution |
Particle Size Distribution By Malvern Mastersizer 2000 D50 = 80um ± 20 |
|
Thickness |
The nominal thickness of the glass is Av.5±2 microns, can be customized. |
|
Surface coatings |
Glass flake materials are offered with the option of surface pre-treatment with a range of silane coupling agents, listed below (typically 0.8-1.2%wt) : |
|
3-Aminopropyltriethoxy Silane Vinyl trimethoxy Silane γ-Glycidoxypropyltrimethoxy Silane Methacryloxypropyltrimethoxy Silane |
